TN 32
| Model | Bore size |
Port size | Standard Stroke (mm) |
Max.Cylinder principle force |
Piston OD. | Body type | Valve type | Max.operating pressure |
| TN 10 | 10 | M5 | 5-50 | 4Kgf | 6 | Y-Y joint I-I joint |
TN | 0-10 kgf/cm² |
| TN 16 | 16 | M5 | 5-100 | 8Kgf | 8 | |||
| TN 20 | 20 | M5 | 5-100 | 14Kgf | 10 | |||
| TN 25 | 25 | PT1/8 | 5-100 | 28Kgf | 12 | |||
| 32 | PT1/8 | 5-100 | 44Kgf | 16 |
