| Model | Thread | Orifice mm | CV Value | Working Pressure | Coil Class | ||||||||||
| Min Pressure | Max pressure | Coil Class | Power | ||||||||||||
| Air Masghgas | Watre hot water Liquid | Liqht oil ≤ 20CST | Steam | VA | W | ||||||||||
| AC | DC | AC | DC | AC | DC | AC | DC | AC220 | DC24V | ||||||
| FSP-10B | 3/8″ | 10 | 4.8 | 0.5 | 25 | 20 | 25 | 20 | 20 | 20 | 10 | 10 | F | 24 | 18 |
| FSP-15B | 1/2″ | 15 | 4.8 | 0.5 | 25 | 20 | 25 | 20 | 20 | 20 | 10 | 10 | F | 24 | 18 |
| FSP-20B | 3/4″ | 20 | 9 | 0.5 | 25 | 20 | 25 | 20 | 20 | 20 | 10 | 10 | F | 24 | 18 |
| FSP-25B | 1″ | 25 | 13 | 0.5 | 25 | 20 | 25 | 20 | 20 | 20 | 10 | 10 | F | 24 | 18 |
